Description
Specifications:
Power output: 2.4 kW
Cylinder displacement: 50.2 cm³
Maximum power speed: 9000 rpm
Idling speed: 2700 rpm
Torque, max.: 2.6 Nm
Torque, max. at rpm: 7200 rpm
Clutch engagement speed (±120): 4300 rpm
Fuel consumption: 504 g/kWh
Fuel consumption: 1.15 kg/h
Spark plug: NGK BPMR7A, Champion RCJ7Y
Electrode gap: 0.5 mm
Ignition module air gap: 0.3 mm
Oil pump type: Fixed flow
Oil pump capacity Max: 13 ml/min
Oil pump capacity Min: 13 ml/min
Exhaust emissions (CO2 EU V): 742 g/kWh
Bar length (inch): 18″
Chain type: H30
Sprocket type: Spur 7
Recommended bar length, max: 20 in
Recommended bar length, min: 13 in
Weight (excl. cutting equipment): 4.9 kg
Lubricant type: Husqvarna 2 stroke or equiv. at 50:1
Oil tank volume: 0.26 l
Sound power level, guaranteed (LWA): 115 dB(A)
Sound power level, measured: 113 dB(A)
Sound pressure level at operators ear: 104 dB(A)
Equivalent vibration level (ahv, eq) front handle: 3.1 m/s²
Equivalent vibration level (ahv, eq) rear handle: 4.9 m/s²
